2025년 11월 10일

Item 계열 컴포넌트
Item
- 가장 기본적인 UI 컴포넌트
- 위치/크기 등 기본 property
Rectangle
- Item을 상속받아 만들어짐
- 간단한 직사각형
- border, radius, color 등 지원
Text
- text: property 사용
- 폰트, 크기, 색상, wrapMode(NoWrap, WordWrap, WrapAnywhere 등) 지원
- source를 통해 이미지 표시
- State 값을 통해 이미지 로딩 수준 표시 가능
Button
- onclicked: 를 통해 클릭 이벤트 발생 (vanila JS 문법)
ListView
- 목록 형태 데이터 표현
- model과 delegate 설정이 핵심
- 방향 설정 property(Qt.Horizontal, Qt.Vertical / Qt.LeftToRight, Qt.RightToLeft 등) 제공
Slider
- 범위 내 값 선택이 가능한 Slider
- Snap 기능 지원 (눈금별 Snap)
Switch
- 토글 스위치 사용
- onCheckedChanged: 이벤트 지원
- signal ↔ slot 개념. signal에서 slot으로만 보낼 수 있음 (이벤트 / 핸들러)
TextField
- placeholderText: property 제공
ProgressBar
- value 값을 통해 진행률 표시 가능
- 진행의 끝을 알 수 없으면 inderterminate: true; 프로퍼티 사용
ScrollView
- 내용이 많을 때 스크롤뷰에 내용을 넣으면 스크롤하며 내용을 확인할 수 있음
- QT QML의 스크롤뷰에 기본적으로 bouncing 효과(스크롤 끝에 도달하면 overscroll되며 튕기는 효과)가 적용되어 있는데, 이를 비활성화시키는 방법은 다음과 같다.
ScrollView { id: root ... Component.onCompleted: { root.contentItem.boundsBehavior = Flickable.StopAtBounds } }
버전에 따라 지원되지 않는 경우도 있다는데, 그 때는 아래 방법을 사용해본다.
ScrollView { ... Binding { target: scrollView.contentItem property: "boundsBehaviour" value: Flickable.StopAtBounds } }
> Window 계열 컴포넌트
Window
독립적인 윈도우
자체적인 렌더링 컨텍스트 소유
modal : 다른 창 조작 금지 유무
flags : 윈도우 flag (https://doc.qt.io/archives/qt-5.15/qt.html#WindowType-enum)Window { visible: true width: 300 height: 2200 title: "Custom Window"
flags: Qt.FramelessWindowHint |
Qt.WindowStaysOnTopHint
Text {
text: "This window has custom flags!"
anchors.centerIn: parent
}}
`ApplicationWindow`
- 메뉴 바, footer, header 등의 윈도우 구성 요소 제공
- Window를 상속받아 만들어짐ApplicationWindow {
visible: true width: 640 height: 480 title: "My Application"
Text { text: "Hello, World!" anchors.centerIn: parent } }
`Tooltip`
- Button 등에서 지원Button { text: "Hover me" // 마우스 커서가 버튼 위에 올라와 있는 상태일 때 Tooltip 표시
ToolTip.visible: hovered ToolTip.text: "This is a tooltip!" }
`Popup`
- 사용자에게 추가 입력을 요청할 때 등에 임시 UI로 사용Popup { id: myPopup width: 200 height: 200 modal: true focus: true Rectangle { color: "white" border.color: "black" anchors.fill: parent Text { text: "This is a popup" anchors.centerIn: parent } } } Button { text: "Show Popup" onClicked: myPopup.open() }
> Position
Manual Position
x, y, z를 통해 부모 컴포넌트의 좌표계에 어디에 위치할지 결정 (좌상단 기준)
같은 z값(depth)에 있는 컴포넌트를 sibling으로 명칭함
수동으로 위치를 조정하는 것이기 때문에 반응형과 같은 디자인에서 적합하지 않고 디버깅이 어려움.
Anchor
한 요소의 한 측면(상/하/좌/우)을 다른 요소의 특정 측면에 고정함
<img src="https://velog.velcdn.com/images/usfree/post/90449eb8-59d1-4b0b-9277-2fd4468eb044/image.png" style="width: 60%">
anchors.centerIn을 통해 요소의 정가운데에 위치 가능
anchors { horizontalCenter : parent.horizontalCenter verticalCenter: parent.verticalCenter }
anchors.centerIn : parent //정 가운데
anchors.fill: parent //부모의 요소를 가득 채움
- 서로 충돌하는 앵커를 설정하면 안됨. ex) anchors.left와 anchors.right를 동시에 설정
- col, row, grid layout 등에서는 anchor가 설정이 되지 않음.
Column / Row
Row는 자식 요소를 수평 방향으로 일렬로 정렬하고, 내부적으로 크기와 위치를 유지함.
Column은 수직 방향으로 일렬 정렬, Row와 마찬가지로 자식들의 크기와 위치를 유지함.
spacing을 통해 자식 요소간 간격 설정이 가능함.
Flow
자식 요소들을 수평으로 배치하고, 공간이 부족해지면 (부모 요소의 크기가 작아지면) 다음 줄로 넘어가는 방식으로 정렬
컨테이너 크기에 따라 자식 요소를 동적으로 재배치해주는 것
anchor의 지정이 필요함Flow { anchors.fill: parent spacing: 10 width: 300 }
`GridLayout`
- 자식을 그리드 형태로 정렬해줌
- Flow와 다르게 컨테이너의 크기를 줄어들어도 개행이 일어나지는 않음.GridLayout {
anchors.fill: parent
columns: 3</p>
//default Spacing값 = 5
rowSpacing: 10
columnSpacing: 10
//첫 번째 행
Rectangle {
color: "red"
width: 100
height: 100
Layout.row: 0
Layout.column: 0
}
Rectangle {
color: "green"
width: 100
height: 100
Layout.row: 0
Layout.column: 1
}
Rectangle {
color: "blue"
width: 100
height: 100
Layout.row: 0
Layout.column: 2
}
//두 번째 행
Rectangle {
color: "black"
width: 100
height: 100
Layout.row: 1
Layout.column: 0
}
Rectangle {
color: "lightpink"
width: 100
height: 100
Layout.row: 1
Layout.column: 1
}
Rectangle {
color: "lightblue"
width: 100
height: 100
Layout.row: 1
Layout.column: 2
}}
`StackLayout`
- 여러 컴포넌트를 쌓아 놓고, 각 시점에 하나의 컴포넌트만 보여줌. (사용자가 여러 페이지나 뷰를 전환할 수 있음)
- currentIndex 속성을 통해 현재 활성화된 자식 컴포넌트를 제어
StackLayout {
id: stackLayout
width: 300
height: 300</p>
Rectangle {
color: "lightblue"
width: parent.width
height: parent.height
}
Rectangle {
color: "yellow"
width: parent.width
height: parent.height
}}
Button { text: "Newt Page" onClicked: { stackLayout.currentIndex = (stackLayout.currentIndex + 1) % stackLayout.children.length } }
### Mouse Event
`MouseArea`
- 마우스 Area에 클릭/커서 위치 변경/드래그 등 다양한 마우스 이벤트를 캡쳐해서 행동 생성 가능
각종 이벤트
MouseArea { anchors.fill: parent onClicked: { console.log("Mouse Clicked at: ", mouse.x, ".", mouse.y) }
onDoubleClicked: {
}
onEntered: {
}
onExited: {
}
onPositionChanged: {
}}
- Drag & Drop
Rectangle {
id: draggableRect
width: 100
height: 100
color: "lightpink"
x: 10
y: 10
z: 1</p>
MouseArea
{
id: dragArea
anchors.fill: parent
drag.target: draggableRect
onReleased: {
if (dropRect.contains(mapToItem(dropRect, dragArea.mouseX, dragArea.mouseY)))
{
dropRect.color = "black"
dropRect.name = "Dropped Here"
}
}
}}
Rectangle { id: dropRect width: 200 height: 200 color: "lightgray" anchors.centerIn: parent property string name: "Drop Here"
Text {
id: dropText
text: dropRect.name
color: "green"
anchors.centerIn: parent
}}
`TapHandler`
터치도 함께 인식함
Rectangle { width: 100 height: 100 color: "lightpink"
TapHandler {
onTapped: console.log("Rect Tappedd");
onDoubleTapped: console.log("Rect double Tapped");
onLongPressed: console.log("Rect long Pressed");
}}
`HoverHandler`
- 마우스 호버 이벤트 처리
Rectangle {
width: 100
height: 100
color: "lightpink"</p>
Text {
id: rectText
text: "Hover me"
anchors.fill: parent
font.pointSize: 14
}
HoverHandler {
id: hoverHandler
acceptedDevices: PointerDevice.Mouse
cursorShape: Qt.PointingHandCursor
}}
`QML Function`
- function 키워드를 통해 함수 작성 가능
- 함수는 컴포넌트 내에서 로컬 범위로 접근
- 슬롯이나 속성 바인딩에서 호출될 수 있음
Rectangle {
id: rectangle
//width: 200
//height: 200
anchors.fill: parent</p>
//vanila js 문법 사용
function calculateArea(width, height)
{
return width * height
}
Text {
id: areaText
//property에 함수 바인딩
text: "Area: " + rectangle.calculateArea(rectangle.width, rectangle.height)
}}
- *.js 파일에 함수 별도 정의
/* mathFunctions.js */
.pragma library
function add(x, y) { return x+y; }
function multiply(x, y) { return x*y; }
/* main.qml */
import "mathFunctions.js" as MathFunc //as 별칭은 대문자로 시작
Window { width: 640 height: 480 visible: true title: qsTr("Example")
Item {
Component.onCompleted: {
// 해당하는 UI 컴포넌트가 생성되었을 때, 수행할 액션 정의
console.log("3+5 =", MathFunc.add(3, 5))
console.log("3*5 =", MathFunc.multiply(3, 5))
}
}}
`Signal ↔ Slot`
Signal: 어떤 이벤트가 발생했을 때 발송되는 메세지
Slot: Signal을 수신하여 특정 동작을 수행하는 함수
1Depth 예시
Item { anchors.fill: parent
Rectangle {
width: 200; height: 100;
color: "lightblue"
signal buttonClicked(string msg) // msg : string
onButtonClicked: (msg) => {
console.log(msg)
}
Button {
text: "Click me"
anchors.centerIn: parent
onClicked: {
parent.buttonClicked("Button was clicked")
}
}
}}
- 2Depth 예시
Item {
anchors.fill: parent</p>
Rectangle {
id: parentRect
width: 300; height: 200;
color: "lightblue"
signal parentSignal(string msg)
onParentSignal: (msg) => {
console.log("Received in parent:", msg) // 4) 부모 시그널 수신
}
Rectangle {
id: childRect
width: 200; height: 100
color: "lightpink"
anchors.centerIn: parent
signal childSignal(string msg)
onChildSignal: (msg) => {
console.log("Received in child:", msg) // 2) 자식 시그널 수신
parentRect.parentSignal("Parent received child's signal") // 3) 부모 시그널 발생
}
MouseArea {
anchors.fill: parent
onClicked: childRect.childSignal("Child was clicked") // 1) 자식 시그널 발생
}
}
}}
`Custom QML Component`
- Custom Button 예시
/* CustomButton.qml */
import QtQuick 2.15
Rectangle { id: root width: 100 height: 40 color: "lightpink" radius: 10
signal clicked() //onClicked 동작 순서 (2)
Text {
text: "Click Button"
anchors.centerIn: parent
}
MouseArea {
anchors.fill: parent
onClicked: { //onClicked 동작 순서 (1)
root.clicked()
root.color = "cyan"
}
}}
/* main.qml */
CustomButton { anchors.centerIn: parent onClicked: { //onClicked 동작 순서 (3) console.log("Button Clicked") } }
- State 관리를 가진 Advanced Button 예시
/* AdvancedButton.qml */
Rectangle { id: root width: 100; height: 40 color: "lightpink" radius: 4 border.color: "black"
property string label: "Clicked Me"
Text {
text: root.label
anchors.centerIn: parent
}
MouseArea {
anchors.fill: parent
onClicked: root.state = ((root.state === "pressed") ? "default" : "pressed")
}
state: "default"
states: [
State {
name: "default"
PropertyChanges {
target: root
color: "lightpink"
border.color: "black"
}
},
State {
name: "pressed"
PropertyChanges {
target: root
color: "black"
border.color: "yellow"
}
}
]}
//Animation Transition transitions: [ Transition { from: "default" to: "pressed"
ColorAnimation {
target: root
property: "color"
duration: 200
}
},
Transition {
from: "pressed"
to: "default"
ColorAnimation {
target: root
property: "color"
duration: 100
}
}]
